149
Using the Camera with a Computer
. To connect the camera to your computer and save files
1. Turn on the camera and press [MENU].
2. On the “Set Up” tab, select “USB” and then press [6].
3. Use [8] and [2] to select “Mass Storage”, and then press [SET].
4. Turn off the camera and then use the USB cable that comes with the
camera to connect it to your Macintosh.
The camera will turn on automatically and battery charging will start (page 19).
The camera may not turn on automatically in the case of certain computer
models or connection conditions. If this happens, press [ON/OFF] (Power) to
turn on the camera.
Make sure that you insert the cable connector into the USB/AV port until you
feel it click securely into place. Failure to insert the connector fully can result in
poor communication or malfunction.
Note that even while the connector is fully inserted, you
still will be able to see the metal part of the connector as
shown in the illustration.
When connecting the USB cable to a USB port, make
sure you align the connector correctly with the port.
Your computer may not be able to recognize the camera
if you connect via a USB hub. Always connect directly to
the computer’s USB port.
The first time you connect the camera to your computer with the USB cable, an
error message may appear on your computer. If this happens, disconnect and
then reconnect the USB cable.
USB port
USB cable (included with camera)
Making sure that the 6 mark on the camera is
aligned with the 4 mark of the USB cable
connector, connect the cable to the camera.
[USB/AV] port
Large connector
Small connector
Terminal cover

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Casio EXILIM EX-ZR300 and is the answer not in the manual?

Casio EXILIM EX-ZR300 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeCMOS
Image stabilizerNo
Total megapixels16.79 MP
Image sensor size1/2.3 \
Supported aspect ratios3:2, 16:9
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072
Digital zoom4 x
Optical zoom12.5 x
Combined zoom199.3 x
Focal length range4.24 - 53 mm
Maximum aperture number7.9
Minimum aperture number3
Lens structure (elements/groups)8/9
Maximum focal length (35mm film equiv)300 mm
Minimum focal length (35mm film equiv)24 mm
Normal focusing range0.05 - ∞ m
Auto focusing (AF) modesMulti Point Auto Focus, Spot Auto Focus, Tracking Auto Focus
Macro focusing range (wide)0.01 - 0.5 m
Light meteringCentre-weighted, Evaluative (Multi-pattern)
ISO sensitivity80, 100, 200, 400, 800, 1600, 3200
Light exposure modesAperture priority AE, Manual, Shutter priority AE
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed4 s
Flash modesAuto, Red-eye reduction
Flash range (tele)0.9 - 2.4 m
Flash range (wide)0.4 - 4.7 m
Flash recharging time5 s
Built-in flashYes
Power source typeAC
Dimensions (WxDxH)104.8 x 28.6 x 59.1 mm
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedAVCHD, H.264, MOV
Maximum video resolution1920 x 1080 pixels
Internal memory52.2 MB
Compatible memory cardsSD, SDHC, SDXC
Maximum memory card size16 GB
Display diagonal3 \
Display resolution960 x 480 pixels
Display resolution (numeric)460800 pixels
USB version2.0
Product colorWhite
Scene modes-
White balanceAuto, Daylight, Manual, Shade
Camera playbackMovie
Self-timer delay2, 10 s
Camera file systemDCF 2.0, DPOF 1.1, Exif 2.3
Battery typeNP-130
Battery life (CIPA standard)500 shots
Cables includedUSB
Weight and Dimensions IconWeight and Dimensions
Depth28.6 mm
Width104.8 mm
Height59.1 mm
Weight165 g
Weight (including battery)205 g
