Names of Parts and Their Functions
@6 Serial connector cover
Use this rubber cover when not using the serial I/F.
@7 Power adaptor port (
)
Connect the power cord from the AC adaptor to this port.
Remove the rubber cover to use it. (See page 37)
UP
DOWN
Operating the Rugged PDA
About Buttons on the Side
The buttons on the side of the Rugged PDA can be used for the following opera-
tions.
Operates in the same way as the Enter key on a
computer.
For example, press the Action button to accept
the item selected on the menu.
Moves the cursor and similar items up and down
on the computer screen. For example, to scroll
the screen down, press the
(DOWN) button.
Using the Stylus
Entering data and most other operations on the Rugged PDA are done with the
stylus. The stylus holder is located on the upper left of the back of the Rugged
PDA.
To use the stylus, remove it from the holder and use it when you make an input on
the screen.
Pressing the
Action button
Pressing the
UP/DOWN
button
