34
Attaching and Removing the Battery Pack
Attaching
1. Turn off the Rugged PDA, and turn it over. Slide the battery pack cover
lock switches with the end of the stylus to FREE (q), and remove the
battery pack cover.
2. Align the battery pack with the slot and insert it into the slot (w). Next,
reattach the battery pack cover, and slide the lock switch from FREE to
LOCK (e).
• Be sure to slide the battery pack cover lock switch to the LOCK
position. If it is not attached correctly, it may fall out while you are
carrying the Rugged PDA and cause a malfunction or injury.
w Insert the battery pack
e FREE LOCK
HA-C21BAT
q LOCK FREE
IT-10_1/25-39-E.p65 06.6.15, 6:40 PM34
