E-12
1 Receiver*1 Outputs voice sound.
2 Indicator 1 Orange: Charging
Green: Charging complete
Red: Battery pack error or the surrounding temperature is out of
the charging temperature range.
3 Indicator 2 Flashes blue when operating via Bluetooth or orange when
operating via W-LAN, GPS or W-WAN. Lights red when there
is a bar code scanning error and lights green when a bar code
scans successfully.
Lights red when the alarm function is activated.
4 Screen The screen displays texts, operations, indicators and so forth. In
addition, operations can be performed and data can be input on
the screen using stylus.
5 Center Trigger Key Used to perform bar code reading. Can be assigned an arbitrary
function.
6 Function Keys Used when starting a pre-registered application.
7 Power Key Turns the power on and off.
8 Enter Key Press when nishing entering numerical values or when moving
to the next step.
9 Mode Key The key switches the character input mode, either characters in
lowercase letter or characters in uppercase letter.
10 Fn Key Used to make various settings in combination with the function
keys or numeric keys or when starting a pre-registered
application.
11 CLR Key Used to clear one letter to the left of the cursor.
12 Microphone*1 Used for audio input (including voice).
13 Speaker Generates audio and buzzer tones.
14 Numeric Keys Used to enter numeric values and decimal points.
15 Cursor Key Perform the same functions as the up and down arrow keys on a
PC keyboard.
16
Barcode Reader
Laser light or LED light is emitted from this window that reads
bar codes.
17 NFC Reader *2 Holding a contactless IC card up to this reader allows data to be
read from and written to the card.
18 microUSB Port For connecting to microUSB cable (HA-N81USBC).
19 Headset Jack Used to connect an earphone-microphone headset.
20 L Trigger Key Used to perform bar code reading.
21
microSD Card Slot
microSD card slot.
22 R Trigger Key Used to perform bar code reading.
23 Camera Lens *2 Takes photos.
