Casio KL-120 User Manual

E-9
Tape Cartridges
Use the procedures described below to load a tape cartridge into the Label
Printer.
Important!
• Never try to push the tape back into the cassette. Once tape is out of the
cassette, there is no way to wind it back in. Trying to do so can cause operational
problems with the Label Printer.
• The following are the tape widths that can be used with this printer: 6mm,
9mm, 12mm, 18mm.
To load a tape cartridge
1. Make sure that the Label Printer is turned off.
2. Open the back cover while pressing down on
its lock.
3. Remove the stopper from a new tape cartridge and check to see that the
tape is ready to use.
• Make sure that the tape is under the tape guide and that it is not bent or
twisted.
4. Pull the tape out about 3cm.
Important!
• Once tape is pulled out, there is no way to get it
back into the cartridge.
• Never use excessive force when pulling on the
tape. Doing so can cause the ink ribbon to break,
creating the risk of malfunction.
3. Release the PRINT, SPACE, and ON/OFF keys.
4. Press SET to initialize the Label Printer or ESC to abort the reset operation
without initializing anything.
The tape width selection screen appears after initialization is complete.
5. Use z and x to select the width of the tape you will use and then press
SET.
Display Language Setting
You can select English, German, French, Italian, or Spanish as the language to
be used for display messages. For information about how to change the language
setting, see page E-22.
Auto Power Off Function
If you do not perform any key operation for about six minutes, the Label Printer
automatically turns power off. To restore power, press ON/OFF.
Retrieving a Sentence from Memory
If power is turned off or if Auto Power Off is triggered while you are creating a
sentence, the sentence that was being created is saved temporarily in printer
memory. The next time you turn on power, the message “[SET] TO RECALL” will
appear. Pressing SET will display the sentence currently stored in memory.
* A sentence being created with Layout Printing cannot be restored.
NO!
OK!
Tape guide
Tape
Ink ribbon
(under the tape)

Casio KL-120 Specifications

General

Type	Printing
Cover	No
Form factor	Desktop
Control type	Buttons
Product color	Black
Housing material	Plastic
Digits	16 digits
Display type	LCD
Display number of lines	2 lines
Print type	Thermal
Maximum roll width	18 mm
Battery type	AA
Power source	Battery
Auto power off	Yes
Battery technology	Alkaline
Power consumption (typical)	9 W
Number of batteries supported	2

Weight and Dimensions

Depth	115 mm
Width	189 mm
Height	54.5 mm
Weight	430 g
