14
EN
Part 6 Confi guring Form Settings
You can use the procedure in this section to confi gure direction, mirror,
alignment, pitch, and tape length settings.
Confi guring Direction, Mirror, Align, and Pitch Settings
1. Input the text you want.
2. Press .
3. Use and to select the item you want to change and then press
OK
.
4. Use
and to change the setting.
5. Press
OK
to return to the text input screen.
When this setting
is selected:
Use and to select the option you want:
DIRECTION HORIZONTAL: Positions text from left to right.
VERTICAL: Positions text from top to bottom.
MIRROR NORMAL: Prints the tape normally.
MIRROR: Prints the tape in mirror image onto
special optionally available iron transfer tape.
ALIGN LEFT: Aligns text fl ush left.
CENTER: Centers text.
RIGHT: Aligns text fl ush right.
EQUAL: Equally spaces text to fi ll the entire
space available.
PITCH
• Specify one of the following settings for the pitch
(space between characters): “NONE” (0 mm),
NARROW” (1 mm), or “WIDE” (2 mm). Changing
this setting also causes the tape length to change
accordingly.
• This setting cannot be changed when EQUAL is
selected for the ALIGN setting, and when FIX is
selected for the TAPE LENGTH setting.
Tape Length Setting
You can use either of the methods below to specify the tape length.
x
AUTO:
Automatically adjusts tape length in accordance with the number of
characters.
x
FIX:
Maintains a fi xed tape length in the range of 0cm (0”) to 99.9cm
(39
5
/
16
”).
To have tape length set automatically (AUTO)
1. Press .
2. Use
and to select
AUTO
, and then press
OK
.
To specify a fi xed tape length (FIX)
1. Press .
2. Use
and to select
FIX
.
3. Use
and
to specify the tape length and then press
OK
.
x
Each press of (–) or (+) changes the current length setting by 0.1.
x
You can also input a value for the tape length.
Note
x
Brackets to the left and right of the display tape length value provide the
information described below.
[xx.x cm]: Print will be the specifi ed length.
(xx.x cm]: Print will be the specifi ed length, but text will be compressed
horizontally.
xx.x cm]: Print will be longer than that specifi ed length.
