Casio Privia PX-770 User Manual

Getting Ready
EN-53
11. After checking to make sure the six screws
that secure side panels

and

are fully
tightened, cover the heads of the screws with
screw caps

.
1. Making sure that the pedal unit cable plug is
oriented as shown in the illustration below,
plug it into the pedal connector on the bottom
of the piano.
a.Press the plug fully into the connector as far as it will
go.
b.Use the clips  to secure the pedal cable to two
locations on side panel .
2. Insert the plug of the AC adaptor that comes
with the Digital Piano into its power terminal
(PX-870: 24VDC, PX-770: 12VDC).
3. Plug the power cord of the AC adaptor that
comes with the Digital Piano into a household
power outlet as shown in the illustration
below.
To connect the cable
K
L
b.
a.
AC adaptor plug
Supplied AC adaptor
Household power outlet
AC adaptor
Power cord

Casio Privia PX-770 Specifications

General

Product color	White
USB port	Yes
Headphone outputs	2
USB connector type	USB Type-B
Keys quantity	88 keys
Number of keyboard sensitivity levels	3
Sound effects	Brilliance, Chorus, Flanger/Digital Signal Processing (DSP), Reverberation
Tones quantity	19
Brilliance type	-3 to 0 to 3
Tweeter diameter	120 mm
Metronome tempo range	20 - 255 bpm
Amplifier output power	16 W
Metronome beats per bar	0, 9
Maximum polyphony (notes)	128
Music memory capacity (songs)	10
Reverberation effects quantity	4
Adjustable tone range (octaves)	-2 - 2
Demo songs quantity	60
Mobile operating systems supported	Android, iOS
Recorder/sequencer number of songs	1
Power consumption (min)	18 W

Weight and Dimensions

Depth	299 mm
Width	1391 mm
Height	798 mm
Weight	31500 g
