Casio PX-150 - TOUCH RESPONSE ADJUSTMENT DATA RESET

PX-150
– 45 –

Resetting the Touch Response Adjustment Data
<Caution>
Be sure to reset the touch response adjustment data by following the steps below after
the main PCB or a keyboard component is replaced.
<Applicable Parts>
•Main PCB (MDA1 PCB)
•KEYBOARD UNIT
•Components for the KEYBOARD UNIT
(Refer to the EXPLODED VIEW and PART LIST: KEYBOARD UNIT)
<Reset Procedure>
(1) Hold down the “FUNCTION”, “CONCERT” and “MODERN” buttons at the same time to turn the
power ON.
NOTE: Hold down three buttons until the reset mode starts.
• When the reset mode starts, all LEDs illuminate. Release the three buttons after the LEDs
illuminate.
• The “
P
” (Power) LED remains ON.
<LED status during the reset mode startup>
(2) Press the “SONG” button and then check that the following LEDs are lit.
• Lit in Red: L, R
