Casio SA-5000 User Manual

— 99 —
Item Code No. Parts Name Specification Q R
D2-17.22-25.38 1904 8538 DIODE MA700 00800012 21 B
D18.26.27.35-37 1904 8539 DIODE IN4148 00800920 6 B
D18 1904 8539 DIODE IN4148 00800920 1 B
ZD1 1904 8541 DIODE/ZENER RD9.1EB2 01000200 1 B
ZD2 1904 8542 DIODE/ZENER RD4.3EB2 01000023 1 B
R12.13 RESISTOR 25SJ5.1 ohm 01600508 2 X
R15 RESISTOR 25SJ270 ohm 01600650 1 X
R9 RESISTOR 25SJ390 ohm 01600680 1 X
R10 RESISTOR 25SJ470 ohm 01600690 1 X
R1.5.6.14 RESISTOR 25SJ1Kohm 01601000 4 X
R22 RESISTOR 25SJ4.7Kohm 01601080 1 X
R2.3.24.46.47.57.
58.59.25
RESISTOR 25SJ10Kohm 01601140 9 X
R35-39.43.44.45 RESISTOR 25SJ47Kohm 01601220 8 X
R26 RESISTOR 25SJ47 ohm 01600560 1 X
R11 RESISTOR 1W100 ohm 01604111 1 X
R8 RESISTOR 25SJ51Kohm 01601225 1 X
R23 RESISTOR 25SJ220 ohm 01600640 1 X
C25.28 CAPACITOR/CERAMIC 22pF 50V 01100090 2 X
C2 CAPACITOR/CERAMIC 680pF 50V 01100240 1 X
C5.29 CAPACITOR/CERAMIC 1000pF 50V 01100250 2 X
C23 CAPACITOR/CERAMIC 0.01uF 50V 01100010 1 X
C4.21.22.3?.35.
37-39.16.9.10.
17.19
CAPACITOR/CERAMIC 0.1uF 50V 01100030 13 X
C3 CAPACITOR/CERAMIC 3300pF 50V 01101020 1 X
C22.19.41 CAPACITOR/CERAMIC 100pF 50V 01100170 3 X
CA1 CAPACITOR/ARRAY B9HC0119-15N 01102060 1 X
C30.31.16 CAPACITOR/CERAMIC 0.1uF 50V 01102010 3 X
C8 CAPACITOR/ELECTROLYTIC 1uF 50V 01200850 1 X
C24.27.32 CAPACITOR/ELECTROLYTIC 10uF 16V 01200868 4 X
C20 CAPACITOR/ELECTROLYTIC 10uF 25V 01200870 1 X
C26 CAPACITOR/ELECTROLYTIC 47uF 16V 01200890 1 X
C1.6 CAPACITOR/ELECTROLYTIC 470uF 16V 01200921 2 X
C7 CAPACITOR/ELECTROLYTIC 220uF 50V 01200916 1 X
L1-5.12 CORE/BEAD EXCELSA35V 62100060 6 X
L6-11 COIL ELEXT101KA 62100080 6 X
RA2 RESISTOR/ARRAY 10Kx8 01700030 1 X
RA1 RESISTOR/ARRAY 47Kx8 01700090 1 X
CN1 1904 8543 CONNECTOR B24P-SHF-1AA 04000180 1 C
CN2 1904 8544 CONNECTOR B6P-SHF-1AA 04000050 1 C
CN3 1904 8545 CONNECTOR B9P-SHF-1AA 04000080 1 C
CN4 1904 8546 CONNECTOR B5P-SHF-1AA 04000040 1 C
CN5 1904 8547 CONNECTOR BTK24P-2S-H 03200720 1 C
CN6 1904 8548 CONNECTOR B12B-XH-A 04000270 1 C
CN7 1904 8549 CONNECTOR B4P-SHF-1AA 04000030 1 C
CN8 1904 8550 CONNECTOR 171825-4 04004000 1 C
CN10 1904 8551 CONNECTOR B6B-XH-A 04000232 1 C
CN11 1904 8552 CONNECTOR B2B-EH-A 04001810 1 C
CN12 1904 8553 CONNECTOR B11B-XH-A 04000260 1 C
CN14 1904 8554 CONNECTOR B2P-SHF-1AA 04000010 1 C
CN13 1904 8555 CONNECTOR B2B-XH-A 04005000 1 C
CN19 1904 8556 CONNECTOR 5267-02A-X 04003100 1 C
