— 98 —
Item Code No. Parts Name Specification Q R
L1-4 COIL ELEXT101KA 62100080 4 X
FB1-4 CORE/BEAD EXCELSA35 62100060 4 X
Y1 1904 8635 OSCILLATOR/CRYSTAL 7.3728MHZ 02300370 1 A
CN2 1904 8503 CONNECTOR B4B-XH-A 04000230 1 C
CN8 1904 8509 CONNECTOR B3P-VH 04002710 1 C
CN7 1904 8508 CONNECTOR TM2REA-1212 03202020 1 C
CN3 1904 8505 CONNECTOR B2B-XH-A 04005000 1 C
CN1 1904 8636 CONNECTOR B18P-SHF-1AA 04000130 1 C
CN4 1904 8637 CONNECTOR B7P-SHF-1AA 04000060 1 C
F1 1904 8510 FUSE CCV-2 02500617 1 A
VR1 1904 8638 RESISTOR/VARIABLE B500K EVN4LC 03100360 1 C
87 1904 8512 HARNESS ASSY EAA-2485B 47410930 1 C
56 1904 8779 CONTROLLER ASSY 010002-05 1 A
K/B UNIT
Item Code No. Parts Name Specification Q R
108 1904 8514 PCB EBK-0146 13507470 1 C
101 SHEET/KEY TOP EBA-2707 11402810 1 X
105 FRAME/KEYBOARD COVER EDM-0917 No.345 10201341 1 X
109 PLATE/KEYBAORD COVER ECM-1154A 10101235 1 X
102 1904 8515 BASE TOP (1x1) EBM-0614 YB1 11600230 84 C
150 1904 8516 BASE TOP (1x2) EBM-0615 YB2 11600240 3 C
100 1904 8517 CAP/KEY (1x1) EBM-0612-A YC1 11500140 84 C
149 1904 8518 CAP/KEY (1x2) EBM-0613-A YC2 11500150 3 C
104 1904 8519 HOUSING/STEM EBM-0409 10300030 90 C
1904 8520 RUBBER/CONTACT CA23-443 10300010 84 C
106 STEM/KEY CC22-466 set 84 -
103 1904 8521 SPRING/KEY CA22-444 10400210 84 C
151 1904 8522 PIN/GUIDE CB22-646 12100010 3 C
110 SHEET/INSULATION 170x125x0.2t 13100420 1 X
107 1904 8523 SHEET/RUBBER ECM-0967 12300740 1 A
SCREW TP(P-TITE) 2x8 55100247 18 X
113 1904 8524 HARNESS ASSY EAA-2504 47411000 1 C
1904 8525 K/B ASSY 020013-03 1 C
K/B CONTROLLER UNIT
Item Code No. Parts Name Specification Q R
PCB EBL-0317 13507475 1 X
U15 1904 8526 LSI M38062M3-238FP 00507950 1 A
U7 1904 8527 LSI/S-RAM BR6216B-10LL 00502220 1 A
U5 1904 8529 IC/MOS TC74HC154AP 00606440 1 A
R12.13 1904 8530 IC/MOS TC74HC04AP 00606250 2 A
U8 1904 8531 IC/MOS TC74HC138AP 00602030 1 A
U14 1904 8532 IC/TTL HD74LS07P 00608013 1 A
U9-11 1904 8533 IC M54564P 00600175 3 A
U25 1904 8528 LSIO/EP-ROM TMS27C512-10JL 00501510 1 A
U1 1904 8624 IC/MOS TC74HC14AP 00606290 1 A
T2.4 1904 8534 TRANSISTOR 2SC1815(Y) 00701050 2 B
T3 1904 8535 TRANSISTOR 2SC3303(Y) 00702140 1 B
T6 1904 8536 TRANSISTOR 2SB744 00700210 1 B
T7 1904 8494 TRANSISTOR 2SC2603 00700630 1 B
To Next Page
