— 97 —
SA-5000
PRINTER CONTROLLER
Item Code No. Parts Name Specification Q R
PCB EBL-0387
48600400 1 X
U4 1904 8623 LSI M38002M4-XXSP 00508345(OTP) 1 A
U8 1904 8481 IC TC232CPE 00501420 1 A
U7 1904 8624 IC/MOS TC74HC14AP 00606290 1 A
U2 1904 8625 IC/MOS TC74HC123AP 00606531 1 A
U3 1904 8492 IC M51953AL 00600265 1 A
U5 1904 8626 IC/TTL HD74LS06P 00608012 1 A
U10 1904 8627 LSI/S-RAM BR6265-10LL (SRM2264LC-10) 00502210 1 A
U1 1904 8628 IC MTA001M-F4101 00600810 1 A
U12 1904 8629 IC/MOS TC74HC139AP 00606150 1 A
U13.15 1904 8630 IC/MOS TC74HC541AP 00608150 2 A
Q6-9 1904 8494 TRANSISTOR 2SC2603 00700630 4 B
Q4 1904 8495 TRANSISTOR 2SD1817 00700190 1 B
Q1 1904 8631 TRANSISTOR 2SD1827 00700150 1 B
Q10.11 1904 8496 TRANSISTOR 2SD986 00700240 2 B
Q2.3.5 1904 8493 TRANSISTOR 2SA1115 00700570 3 B
U6 1904 8632 TRANSISTOR/ARRAY STA401A 00703010 1 A
D1 1904 8633 DIODE 1SS136 00800500 1 B
D4.5 1904 8501 DIODE RL102-E 00800915 2 B
D2 1904 8634 DIODE/ZENER RD24EB3 01000363 1 B
D3 1904 8500 DIODE/ZENER RD8.2EB2 01000170 1 B
CAPACITOR/ELECTROLYTIC 1uF 100V 01200852 1 X
C4 CAPACITOR/ELECTROLYTIC 10uF 16V 01200868 1 X
C20-24 CAPACITOR/ELECTROLYTIC 10uF 25V 01200870 4 X
C36 CAPACITOR/ELECTROLYTIC 100uF 50V 01200910 1 X
C31 CAPACITOR/ELECTROLYTIC 100uF 16V 01200906 1 X
C8 CAPACITOR/CERAMIC 220pF 50V 01100200 1 X
C15-19.25.27 CAPACITOR/CERAMIC 1000pF 50V 01100250 7 X
C1.2.5.7.9.11.22.26.
28.32.35.37.38-41
CAPACITOR/CERAMIC 0.1uF 50V 01100030 15 X
C12.13 CAPACITOR/CERAMIC 10pF 50V 01100061 2 X
C6.10.14.39.41 CAPACITOR/CERAMIC 0.01uF 50V 01100010 6 X
C42-44 CAPACITOR/CERAMIC 4700pF 50V 01100272 3 X
C33.34 CAPACITOR/CERAMIC 100pF 50V 01100170 2 X
C3 CAPACITOR/MYLAR 0.01uF 50V 01300110 1 X
R4 RESISTOR/METAL FILM 1/4W 162K 1% 01607040 1 X
R10 RESISTOR 25SJ470 ohm 01600690 1 X
R7.9.31 RESISTOR 25SJ4.7 ohm 01601080 3 X
R2.6.11.14.15.19.20.
27.32.34
RESISTOR 25SJ10Kohm 01601140 10 X
R13.23-26.28 RESISTOR 25SJ3.3Kohm 01601060 7 X
R3.35.38 RESISTOR 25SJ1Kohm 01601000 3 X
R12 RESISTOR 1W47 ohm 01608010 1 X
R5.29.30 RESISTOR 25SJ47Kohm 01601220 3 X
R18 RESISTOR 45SJ2.2Kohm 01601800 1 X
R22 RESISTOR 25SJ100 ohm 01600600 1 X
RA1 RESISTOR/ARRAY 1K x 4 01700239 1 X
RA2.3 RESISTOR/ARRAY 47K x 8 01700090 2 X
