— 106 —
SA-5100
PRINTER CONTROLLER
Item Code No. Parts Name Specification Q R
PCB EBL-0344 00400914 1 X
U1 1904 8481 IC TC232CPE 00501420 1 A
U2 1904 8482 LSI M37702S4BFP 00508750 1 A
U3 1904 8483 IC/MOS TC74HC14AF-TP1 00606770 1 A
U4.5 1904 8484 IC/MOS HD74HC573FP-TL 00608750 2 A
U6 1904 8485 IC LB1650 00601090 1 A
U7.14 1904 8486 IC/MOS TC74AC32F-TP1 00606412 2 A
U8 1904 8487 IC/MOS TC74HC04FP-TP1 00606630 1 A
U9 1904 8488 LSI/FLASH-ROM M5M28F102AFP-10 00600555 1 A
U10 1904 8489 IC TA8428K 00606310 1 A
U11 1904 8490 LSI/CG PT500CG2 00501300 1 A
U12.13 1904 8491 LSI/S-RAM SRM2B256SLMX70 00502430 2 A
U15 1904 8492 IC M51953AL 00600265 1 A
Q1.9.11.13 1904 8493 TRANSISTOR 2SA1115 00700570 4 B
Q2.4.8.10.12 1904 8494 TRANSISTOR 2SC2603 00700630 5 B
Q3 1904 8495 TRANSISTOR 2SD1817 00700190 1 B
Q5.6 1904 8496 TRANSISTOR 2SD986 00700240 2 B
Q7 1904 8497 FET 2SJ177 00700910 1 B
D1 1904 8498 DIODE/ZENER RD3.9EB2 01000005 1 B
D2.14-17 1904 8499 DIODE 1SS176 00800071 5 B
D3 1904 8500 DIODE/ZENER RD8.2EB2 01000170 1 B
D4-13 1904 8501 DIODE RL102-E 00800915 10 B
R1 RESISTOR 16SJ 56 ohm 01606007 1 X
R2.32.44.51.
53.57.58.
68-72.74
RESISTOR 16SJ 4.7Kohm 01606070 14 X
R3.66 RESISTOR 16SJ 22Kohm 01606105 2 X
R4 RESISTOR 16SJ 470 ohm 01606027 1 X
R5.8.23 RESISTOR 16SJ 100Kohm 01606120 3 X
R6 RESISTOR 16SJ 75Kohm 01606115 1 X
R7.14.17.25.
47.49.61-63
RESISTOR 16SJ 33 ohm 01606003 9 X
R9.16 RESISTOR 16SJ 3.3Kohm 01606063 2 X
R10-12.19-21.
36.40.48.50
RESISTOR 16SJ 47Kohm 01606110 10 X
R13.26.27.29.
35.38.39.52.
56.64.77.78
RESISTOR 16SJ 10Kohm 01606090 12 1
R15 RESISTOR 16SJ 20Kohm 01606180 1 X
R18 RESISTOR 16SJ 2Kohm 01606058 1 X
R22 RESISTOR JUMP WIRE L=5 60100040 1 1
R28 RESISTOR 16SJ 30 ohm 01606030 1 X
R30 RESISTOR 16SJ 200 ohm 01606018 1 X
R31.41 RESISTOR 16SJ 220 ohm 01606020 2 X
R33.34.43.45.
46.54.55.59.
60.73.75.79
RESISTOR 16SJ 1Kohm 01606060 12 X
R37 RESISTOR 1W 47 ohm 01608010 1 X
R42 RESISTOR 16SJ 1Mohm 01606040 1 X
R65 RESISTOR 16SJ 6.8Kohm 01606083 1 X
R76 RESISTOR 45SJ 2.2Kohm 01601800 1 X
