Item Code No. Parts Name Specification Q R
CI.6.9 CAPACITOR/ELECTROLYTIC 10uF 16v 01200868 3 X
C2.4.9 CAPACITOR/ELECTROLYTIC 100uF 50v 01200910 2 X
C3.4.7.8.10.11.
19.24.25.27.
30.32.34.36.37.
39-43.45-48.
50-52
CAPACITOR/CERAMIC 0.1uF 50v 01100030 27 X
C5.12.53 CAPACITOR/CERAMIC 0.01uF 50v 01100010 3 X
C13-16.22.23 CAPACITOR/CERAMIC 1000PF 50v 01100250 7 X
C17.18.20.21 CAPACITOR/ELECTROLYTIC 10uF 25v 01200870 4 X
C26 CAPACITOR/ELECTROLYTIC 100uF 16v 01200906 1 X
C28.29 CAPACITOR/CERAMIC 22PF 50v 01100090 2 X
C31.38.44 CAPACITOR/CERAMIC 100PF 50v 01100170 3 X
C33 CAPACITOR/ELECTROLYTIC 47uF 50v 01200200 1 X
CN1 1904 8502 CONNECTOR B25P-SHF-1AA 04000190 1 C
CN2 1904 8503 CONNECTOR B4B-XH-A 04000230 1 C
CN3 1904 8504 CONNECTOR 53047-0610 03200582 1 C
CN6 1904 8505 CONNECTOR B2B-XH-A 04000500 1 C
CN7 1904 8506 CONNECTOR 53047-0410 04003053 1 C
CN8 1904 8507 CONNECTOR 5267-04A-X 04003101 1 C
CN9 1904 8508 CONNECTOR TM2REA-1212 03202020 1 C
CN10 1904 8509 CONNECTOR B3P-VH 04002710 1 C
FB1-4 FERRITE BEAD EXCELSA35V 62100060 4 X
L1-4 INDUCTOR ELEXT101KA(100uH) 62100080 4 X
JP1 WIRE/JUMPER 0Ω 01605015 1 X
F1 1904 8510 FUSE CCV-2 02500617 1 A
Y1 1904 8511 OSCILLATOR/CRYSTAL AT-51 14.7456MHz 02300340 1 A
87 1904 8512 CABLE/JOINT EAA-2485B 47410930 1 C
CLAMP/FERRITE ZCAT1518-0730 21002000 1 X
INSULOCK TIE (comes with the above part) 1 X
56 1904 8513 PRINTER CONTROLLER ASS'Y 010145-01 1 A
KEYBOARD UNIT
Item Code No. Parts Name Specification Q R
108 1904 8514 PCB EBK-0146 13507470 1 C
101 PLATE/KEY TOP EBA-2707 11402810 1 X
105 FRAME/KEYBOARD COVER EDM-0917 NO.345 10201341 1 X
102 1904 8515 BASE TOP(1X1) EBM-0614 YB1 11600230 84 C
150 1904 8516 BASE TOP(1X2) EBM-0615 YB2 11600240 3 C
100 1904 8517 CAP/KEY(1x1) EBM-0612-A YC1 11500140 84 C
149 1904 8518 CAP/KEY(1x2) EBM-0613-A YC2 11500150 3 C
104 1904 8519 HOUSING/STEM EBM-0409 10300030 90 C
1904 8520 RUBBER/CONTACT CA23-443 10300010 84 C
106 STEM/KEY CC22-466 set 84 -
103 1904 8521 SPRING/KEY CA22-444 10400210 84 C
151 1904 8522 PIN/GUIDE CB22-646 12100010 3 C
109 PLATE/KEYBOARD COVER ECM-1154 10101235 1 X
110 SHEET/INSULATION 170 X 125 X 0.2t 13100420 1 X
107 1904 8523 SHEET/RUBBER ECM-0967 12300740 1 A
SCREW TP(P-Tite)2X8 55100247 18 X
113 1904 8524 HARNESS ASS'Y EAA-2504 47411000 1 C
1904 8525 KEYBOARD ASS'Y 020013-03 1 C
