— 108 —
KEYBOARD CONTROLLER UINT
Item Code No. Parts Name Specification Q R
PCB EBL-0317 13507475 1 X
U15 1904 8526 LSI M38062M3-238FP 00507950 1 A
U7 1904 8527 LSI/S-RAM BR6216B-10LL 00502220 1 A
U25 1904 8528 LSI/EP-ROM TMS27C512-10JL 00501510 1 A
U5 1904 8529 IC/MOS TC74HC154AP 00606440 1 A
U12.13 1904 8530 IC/MOS TC74HC04AP 00606250 2 A
U8 1904 8531 IC/MOS TC74HC138AP 00602030 1 A
U14 1904 8532 IC/TTL HD74LS07P 00608013 1 A
U9-11 1904 8533 IC M54564P 00600175 3 A
T2.4 1904 8534 TRANSISTOR 2SC1815(Y) 00701050 2 B
T3 1904 8535 TRANSISTOR 2SC3303(Y) 00702140 1 B
T6 1904 8536 TRANSISTOR 2SB744 00700210 1 B
T7 1904 8494 TRANSISTOR 2SC2603 00700630 1 B
D2-17.22-25 1904 8538 DIODE MA700 00800012 20 B
D18.35-37 1904 8539 DIODE IN4148 00800920 4 B
ZD1 1904 8541 DIODE/ZENER RD9.1EB2 01000200 1 B
ZD2 1904 8542 DIODE/ZENER RD4.3EB2 01000023 1 B
R12.13 RESISTOR 25SJ5.1 ohm 01600508 2 X
R15 RESISTOR 25SJ270 ohm 01600656 1 X
R9 RESISTOR 25SJ390 ohm 01600680 1 X
R10.40-42 RESISTOR 25SJ470 ohm 01600690 4 X
R14.23 RESISTOR 25SJ1Kohm 01601000 2 X
R22.56 RESISTOR 25SJ4.7Kohm 01601080 2 X
R24.25.46.47 RESISTOR 25SJ10Kohm 01601140 7 X
R35-39.43-45 RESISTOR 25SJ47Kohm 01601220 8 X
R26 RESISTOR 25SJ47 ohm 01600560 1 X
R11 RESISTOR 1W100 ohm 01604111 1 X
R8 RESISTOR 25SJ51Kohm 01601225 1 X
C25.28 CAPACITOR/CERAMIC 22pF 50V 01100090 2 X
C2 CAPACITOR/CERAMIC 680pF 50V 01100240 1 X
C5.29 CAPACITOR/CERAMIC 1000pF 50V 01100250 2 X
C23 CAPACITOR/CERAMIC 0.01uF 50V 01100010 1 X
C4.21.22.30. CAPACITOR/CERAMIC 0.1uF 50V 01100030 11 X
C3 CAPACITOR/CERAMIC 3300pF 50V 01101020 1 X
CA1 CAPACITOR/ARRAY B9HC0119-15N 01102060 1 X
C8 CAPACITOR/ELECTROLYTIC 1uF 50V 01200850 1 X
C24.27.32.34 CAPACITOR/ELECTROLYTIC 10uF 16V 01200868 4 X
C20 CAPACITOR/ELECTROLYTIC 10uF 25V 01200870 1 X
C26 CAPACITOR/ELECTROLYTIC 47uF 16V 01200890 1 X
C1.6 CAPACITOR/ELECTROLYTIC 470uF 16V 01200921 2 X
C7 CAPACITOR/ELECTROLYTIC 220uF 50V 01200916 1 X
L1-5.10 CORE/BEAD EXCELSA35V 62100060 6 X
L6-9 INDUCTOR ELEXT101KA 62100080 4 X
RA2 RESISTOR/ARRAY 10KX8 01700030 1 X
RA1 RESISTOR/ARRAY 47KX8 01700090 1 X
CN1 1904 8543 CONNECTOR B24P-SHF-1AA 04000180 1 C
CN2 1904 8544 CONNECTOR B6P-SHF-1AA 04000050 1 C
CN3 1904 8545 CONNECTOR B9P-SHF-1AA 04000080 1 C
