— 117 —
SA5061D
Item Code No. Parts Name Specification Q R
9 1904 8654 PCB/DISPLAY EAL-0315 48400820 1 X
U1 1904 8655 IC SED2800FVA 00607520 1 A
U2 1904 8656 LSI M38022M4-314SP 00508410 1 A
U3 1904 8481 IC TC232CPE 00501420 1 A
U4 1904 8658 LSI/RAM LH5116NA-10 00509010 1 A
8 1904 8659 DISPLAY TUBE 202-SD-08/GYK 11000400 1 A
1904 8660 CUSHION 15x15x3t 60200105 2 X
TR1.3 1904 8534 TRANSISTOR 2SC1815(Y) 00701050 2 B
TR2 1904 8535 TRANSISTOR 2SC3303(Y) 00702140 1 B
D1-4 1904 8539 DIODE IN4148 00800920 4 B
ZD1 1904 8541 DIODE/ZENER RD9.1EB2 01000200 1 B
ZD2 1904 8542 DIODE/ZENER RD4.3EB2 01000023 1 B
C2.11.12 CAPACITOR/ELECTROLYTIC 10uF 16V 01200868 3 X
C21.23 CAPACITOR/ELECTROLYTIC 470uF 16V 01200921 2 X
C22 CAPACITOR/ELECTROLYTIC 220uF 50V 01200916 1 X
SA5060
Item Code No. Parts Name Specification Q R
9 1904 8678 PCB/DISPLY EAL-0316 48400800 1 X
8 1904 8679 DISPLAY TUBE 11LT-11G 11000330 1 A
10 1904 8680 HARNESS ASSY EAA-2509 47411032 1 C
1 1904 8672 CASE/DISPLAY (FRONT) ECM-0920 41500740 1 C
2 1904 8673 CASE/DISPLAY (REAR) ECM-0921 41500750 1 C
3 1904 8674 FILTER/DISPLAY EBM-0924 41500760 1 C
5 1904 8675 SHAFT/DISPLAY (FRONT) EBM-0935 41500770 1 X
4 1904 8676 SHAFT/DISPLAY (REAR) EBM-0934 41500780 1 X
6 1904 8670 BLIND PIECE/SCREW EAM-0955 41500720 2 X
7 1904 8671 BLIND PIECE/SCREW EAM-0956 41500790 3 X
11 1904 8677 HINGE TH-122-3A 61700110 1 X
12 SCREW P.M3x10 SW 55100170 4 X
13 SCREW PTT-P.3x6 55100420 4 X
14 SCREW BTT-P.3x10 55180084 2 X
15 NUT M4 55200020 4 X
1904 8689 CABLE/INTERCONNECTION EAA-2513A 47400140 1 C
SCREW P.3x10 55100159 4 X
1904 8602 BASE/SHAFT EBM-0930 24250411 1 X
1904 8603 COVER/BASE/SHAFT EBM-0931 24250421 1 X
