— 118 —
Item Code No. Parts Name Specification Q R
C5-9 CAPACITOR/ELECTROLYTIC 10uF 25V 01200870 5 X
C24 CAPACITOR/ELECTROLYTIC 1uF 50V 01200850 1 X
C3.4 CAPACITOR/CERAMIC 22pF 50V 01100090 2 X
C17 CAPACITOR/CERAMIC 100pF 50V 01100170 1 X
C18 CAPACITOR/CERAMIC 220pF 50V 01100200 1 X
C27 CAPACITOR/CERAMIC 680pF 50V 01100240 1 X
C30 CAPACITOR/CERAMIC 1000pF 50V 01100250 1 X
C1.10.13-16.29 CAPACITOR/CERAMIC 0.1uF 50V 01100030 7 X
C28 CAPACITOR/CERAMIC 3300pF 500V 01101020 1 X
R15 RESISTOR 25SJ200 ohm 01600630 1 X
R9 RESISTOR 25SJ390 ohm 01600680 1 X
R10 RESISTOR 25SJ470 ohm 01600690 1 X
R14 RESISTOR 16SJ1Kohm 01606060 1 X
R8 RESISTOR 25SJ50Kohm 01601224 1 X
R1-3.16 RESISTOR 25SJ10Kohm 01601140 4 X
R4.5 RESISTOR 25SJ100Kohm 01601250 2 X
R11 RESISTOR 1W100 ohm 01604111 1 X
R12.13 RESISTOR 25SJ7.5 ohm 01600507 2 X
RA1.2 RESISTOR/ARRAY 47Kx4 01700060 2 X
R3.4 RESISTOR/ARRAY 47Kx8 01700090 2 X
Y1 1904 8635 OSCILLATOR/CRYSTAL 7.3728MHZ 02300370 1 A
10 1904 8667 CABLE/JOINT EAA-2510A 47411033 1 C
CVT1 1904 8668 CONVERTER/DC-DC C302 01901540 1 A
F1 1904 8669 FUSE CCV1 02500615 1 A
FB1.2 CORE/BEAD EXCELSA35V 62100060 2 X
J5 WIRE/JUMPER L=10 60100010 1 X
6 1904 8670 PIECE/SCREW BLIND EAM-0955 No. 345 41500720 2 X
7 1904 8671 PIECE/SCREW BLIND EAM-0956 No. 345 41500790 3 X
1 1904 8672 CASE/DISPLAY (FRONT) ECM-0920 No. 345 41500740 1 C
2 1904 8673 CASE/DISPLAY (REAR) ECM-0921 No. 345 41500750 1 C
3 1904 8674 FILTER/DISPLAY EBM-0924 GREEN 41500760 1 C
5 1904 8675 SHAFT/DISPLAY (FRONT) EBM-0935 No. 345 41500770 1 X
4 1904 8676 SHAFT/DISPLAY (REAR) EBM-0934 No. 345 41500780 1 X
11 1904 8677 HINGE TH-122-3A 61700110 1 X
12 SCREW P.M3x10 SW 55100170 4 X
13 SCREW PTT-P.3x6 55100420 4 X
15 NUT M3 55200010 4 X
1904 8602 BASE/SHAFT EBM-0930 No. 345 24250411 1 X
1904 8603 COVER/BASE/SHAFT EBM-0931 No. 345 24250421 1 X
14 SCREW P.3x10 55100159 2 X
