— 119 —
SA5062DH
Item Code No. Parts Name Specification Q R
9 1904 8690 PCB/DISPLAY EAL-0327 48400810 1 X
U1 1904 8691 IC SED2800FVA 00607520 1 A
U2 1904 8656 LSI M38022M4-314SP 00508410 1 A
U3 1904 8481 IC TC232CPE 00501420 1 A
U4 1904 8527 LSI/RAM BR6216B-10LL 00502220 1 A
8 1904 8695 DISPLAY TUBE 202-MD-07G 11000390 1 A
TR1.3 1904 8534 TRANSISTOR 2SC1815(Y) 00701050 2 B
TR2 1904 8535 TRANSISTOR 2SC3303(Y) 00702140 1 B
D1-4 1904 8539 DIODE IN4148 00800920 4 B
ZD1 1904 8541 DIODE/ZENER RD9.1EB2 01000200 1 B
ZD2 1904 8542 DIODE/ZENER RD4.3EB2 01000023 1 B
C2.11.12 CAPACITOR/ELECTROLYTIC 10uF 16V 01200868 3 X
C21.23 CAPACITOR/ELECTROLYTIC 470uF 16V 01200921 2 X
C22 CAPACITOR/ELECTROLYTIC 220uF 50V 01200916 1 X
C5-9 CAPACITOR/ELECTROLYTIC 10uF 25V 01200870 5 X
C24 CAPACITOR/ELECTROLYTIC 1uF 50V 01200850 1 X
C3.4 CAPACITOR/CERAMIC 22pF 50V 01100090 2 X
C17 CAPACITOR/CERAMIC 100pF 50V 01100170 1 X
C18 CAPACITOR/CERAMIC 220pF 50V 01100200 1 X
C27 CAPACITOR/CERAMIC 680pF 50V 01100240 1 X
C30 CAPACITOR/CERAMIC 1000pF 50V 01100250 1 X
C1.10.13-?? CAPACITOR/CERAMIC 0.1uF 50V 01100030 7 X
C28 CAPACITOR/CERAMIC 3300pF 500V 01101020 1 X
R15 RESISTOR 25SJ200 ohm 01600630 1 X
R9 RESISTOR 25SJ390 ohm 01600680 1 X
R10 RESISTOR 25SJ470 ohm 01600690 1 X
R14 RESISTOR 25SJ1Kohm 01606060 1 X
R8 RESISTOR 25SJ50(51)Kohm 01601224 1 X
R1-3.16 RESISTOR 25SJ10Kohm 01601140 4 X
R4.5 RESISTOR 25SJ100Kohm 01601250 2 X
R11 RESISTOR 1W100 ohm 01604111 1 X
R6.7 RESISTOR 25SJ33Kohm 01601200 2 X
R12.13 RESISTOR 25SJ0 ohm 01605015 2 X
RA1.2 RESISTOR/ARRAY 47Kx4 01700060 2 X
RA3.4 RESISTOR/ARRAY 47Kx8 01700090 2 X
Y1 1904 8635 OSCILLATOR/CRYSTAL 7.3728MHZ 02300370 1 A
10 1904 8667 FLAT CABLE ASSY EAA-2510A 47411033 1 C
CVT1 1904 8668 CONVERTER/DC-DC C302 01901540 1 A
F1 1904 8669 FUSE CCV1 02500615 1 A
FB1.2 CORE/BEAD EXCELSA35V 62100060 2 X
