— 24 —
Ext. Port #1 Ext. Port #2 Ext. Port #3 Ext. Port #4
Pin J13 J14 J15 J16
1 +12V/CD +12V/CD CD CD
2 Rxd Rxd Rxd Rxd
3 Txd Txd Txd Txd
4 DTR DTR DTR DTR
5 Gnd Gnd Gnd Gnd
6 DSR DSR DSR DSR
7 RTS RTS RTS RTS
8 CTS CTS CTS CTS
9 +5V/RI +5V/RI RI RI
[Another 4 of the Serial Ports]
5-5-5. Ethernet Port
The connector used conforms to the industry-standard RJ-45. Refer to the relevant documents.
5-5-6. Drawer Port
Pin Number Signal Name Signal Direction
1FG NA
2 Drawer kick drive A Output
3 Drawer open/close Input
4 +24V NA
5 Drawer kick drive B NA
6SG NA
[Cash Drawer]
