Casio XW-P1 User Guide

General Guide
E-7
bp
Use these buttons to select a tone number, performance number, etc. ☞ Page E-20
bq
Use the six buttons on the right to move the cursor on the screen, and the minus (–) and plus (+) buttons to change a
displayed value. Press the [MENU] button to display a menu of options for the operation you are currently performing.
☞ Page E-21
br
Use these keys for one-touch alteration of the pitch of a sound. ☞ Page E-36
bs
Use [BENDER] to bend notes and [MODULATION] to add vibrato to notes. ☞ Page E-35
Back
See the next page.
bp
bq
br
Right
bs
Lower left

Casio XW-P1 Specifications

General

Polyphony	64 notes
Arpeggiator	Yes, 6 types
Power Supply	D batteries x 6, AC Adapter
Dimensions	95.7 x 39.7 x 11.1 cm
Weight	13.2 lbs
Effects	Reverb, Chorus, Delay, Distortion, Rotary Speaker
Display	LCD
User Tones	100
Inputs/Outputs	USB
User memory	100 user tones
Controllers	Pitch Bend Wheel, Modulation Wheel
Inputs	Line In
Outputs	1/4" L/Mono, R output
Keyboard	61 keys
Connections	USB
