G
as Type Natural Gas (G20) Cat
I
2H
L
PG (G31) Cat
I
3P
Gas Connection 8mm 8mm
N
umber of Injectors One One
Injector size Stereomatic 072 Bray 92/150
Control Max Operating Temperature 80
o
c80
o
c
Inlet Pressure Cold 20 mbar (8” W.G.) 37 mbar
Heat Input (Gross) 6.9 kW 5.1 kW
W
e
ight 11.8 kg 11.8 kg
1.
Loose coals - The ceramic coals supplied with this appliance can be replaced at service intervals depending
on their condition. If the coals do require replacement, the consumer can do so provided that the Ceramic
Component Layout Instructions (pages 18-19) are adhered to. Under no circumstances should additional/extra
coals be added. Only genuine Legend replacement parts should be used.
Order Ref:
VLC06
2. Front Coal, and Fuel Bed, Side Cheeks and Rear Coal - All these ceramic components can be replaced at
service intervals depending on their condition. If the coals do require replacement, the consumer can do so
provided that the Ceramic Component Layout Instructions (pages 18-19) are adhered to. Only genuine Legend
replacement parts should be used.
Order Ref:
VFC02, VFM03, VCSC04, VCR05
3. Oxygen Depletion Sensing Pilot - In the unlikely event of a pilot failure, the pilot assembly should only be
replaced by a
GAS SAFE Registered Engineer. The user must not carry out this work.
Order Ref:
NG - LEG27, LPG - LEG47
4. Motorised Valve - In the unlikely event of valve failure, the assembly should only be replaced by a
GAS SAFE Registered Engineer. The user must not carry out this work.
Order Ref:
LEG48
5. Handset - Order Ref: LEG29
6. AA Battery Pack - When the batteries are becoming discharged, the fire will emit a continuous beeping
sound. Please replace with good quality Alkaline or Lithium 6 x 1.5V AA.
Order Ref:
LEG56
7. EDB20 Control Panel - In the unlikely event of a control panel failure, the panel should only be replaced by a
GAS SAFE Registered Engineer. The user must not carry out this work.
Order Ref:
LEG51
TECHNICAL DATA
9
REPLACEMENT PARTS
