ASSEMBLY GUIDE
7
START WITH THE SUSPENSION WISHBONES
35
mm
35
mm
81Nm
AB
AJ
AM
1
2
3
AJ
35
mm
35
mm
81Nm
AA
AJ
AG
35
mm
35
mm
47Nm
35
mm
35
mm
47Nm
AD
AH
AC
AH
REPEAT
