Caterham 7 - Let There be Lights

ASSEMBLY GUIDE
16
LET THERE BE LIGHTS
PARTS
FIXINGS
TOOLS
TIPS
PART
NUMBER
QTYUSED ON
1CA
71080
6
Indictor assembly to
indicator pod
2CB
71077
2
Side repeater earth
on wingstay
3CC
71079
4
Rear light cluster
upper fixing
4CD
71078
4
Rear light cluster
lower fixing
5CE
NMYF6
2
Horn bracket to
steering rack
platform
(160/270/310)
6CF
WPH1/4
2
Horn bracket to
steering rack
platform
(160/270/310)
7CG
BM8X50
1
Through steering
rack platform &
spacer
(420)
8CH
WPH5/16
2Bolt head/nut
9CI
NMYF8
1Horn bolt
Drawings are for illustrative purposes only and are not to scale.
BASIC
DESCRIPTION
ILLUSTRATION
Screw 10 x ¾
"
Black Supaflange
Page 1 of 1
Screw 12 x 1"
Self tapping
Screw 8 x ½"
Black Supaflange
Screw 12 x 1½
"
Self tapping
LIGHTING & HORNS
ITEM
Pack
45
SERIAL
NUMBER
PACK NUMBER
30L002B
C
Nyloc Nut M6
Plain Washer
¼"
Heavy duty
Bolt M8 x 5
Grade 8.8
Plain Washer
5/16"
Nyloc Nut
M8
x6
Headlight assembly
Indicator assembly
Indicator pod
17mm
24mm
17mm
1
3
2
The wiring for the headlights is attached to the chassis when
you receive your kit. The wires go through the hole in the end
of the headlight bracket and out of the other hole in order to
go up into the headlight and over to the indicator.
Jamie A
Headlight bracket
4
