Caterham 7 - The Side Impact Bar

ASSEMBLY GUIDE
156
PARTS
FIXINGS
TOOLS
TIPS
AND THE SIDE IMPACT BAR
17mm
19mm
⁄"
19mm
PART
NUMBER
QTYUSED ON
1RA
BM12X120
1 A-frame
2RB
BFCH7/16X1.5
1
Boss on top of
chassis
3RC
SM10X25
1Front cage brac ket
4RD
WPHM10
1Front cage brac ket
5RE
WSH7/16
1
Boss on top of
chassis
Drawings are for illustrative purposes only and are not to scale.
R
SERIAL
NUMBER
46
Pack
PACK NUMBER
30P009C
SIDE PROTECTION BAR SERIES 3
This pack may include extra fasteners to cover different options
ITEM
BASIC
DESCRIPTION
ILLUSTRATION
Bolt M12 X 120
Grade 10.9
Spring Washer
7/16"
Page 1 of 1
Caphead Bolt
7/16" X 1 1/2"
Set screw M10
X 25 Grade
10.9
Plain Washer
M10
x1
x1
x1
x1
x1
Use washers from rollcage pack
