Caterham 7 - The Engine Is Going in

38
AT LAST, THE ENGINE IS GOING IN
PARTS
FIXINGS
TOOLS
TIPS
Engine mounts
Engine rubbers
6mm
8mm
⅜”
13mm
13mm
15mm
1
2
Protect the chassis
with soft stuff such
as cardboard or folded
towels/blankets. Just
not your fingers.
Tiago O
It's 54Nm for the
bolts tightened with
the 8mm hex socket
& 30Nm for the 6mm
hex socket.
Grant P
It will fit – keep at it!
Rich T
Removing the
tensioner will make
things much easier.
James A
When fitting the engine rubbers and mounts,
do them as loosely as possible so you can
wiggle things to get bolts in. Tighten it all up
gradually once all the bolts are in.
Jamie A
+
Tensioner
3
ASSEMBLY GUIDE
