Caterham 7 - Fitting the Handbrake

ASSEMBLY GUIDE
90
FITTING THE HANDBRAKE
PARTS
FIXINGS
TOOLS
TIPS
13mm (x2)
Handbrake assembly
Handbrake clevis
Handbrake cable
Handbrake pulley
Handbrake clevis pin
Pulley clevis pin
1
3
6
2
5
4
Miscellaneous pack
• Setscrew 8 (x25)
• Washer M8
• Washer M6
Remember to put a loop in
inner cable around pulley.
Grant P
Cable tie adjuster
end of cable to diff.
Dan D
