13
ASSEMBLY GUIDE
1 x ⅛
IT’S TIME FOR THE WINGSTAYS
WIDE
TRACK
35
mm
35
mm
54Nm
35
mm
35
mm
81Nm
35
mm
35
mm
61Nm
AS
AR
STANDARD TRACK
1
2
REPEAT
35
mm
35
mm
54Nm
