OWNER’S MANUAL PAGE 11
Assembly
Assembly instructions
Assembly set up and fitting performed by authorized Catrike dealer.
Your Catrike should be fully assembled, tested and fine-tuned by your Catrike dealer or local
bike store. Here are the assembly instructions in order to show how this process is done.
A complete Catrike includes:
✓ Main frame with cups for headsets in place. The idler pulley and chain tube also are pre-
assembled and installed on the frame.
✓ Quick-release boom clamp
✓ Boom
✓ Seat mesh
✓ One tie rod with two aluminum rod-end bearings, jam nuts, and tie rod bolts
✓ Two spindle/axle assemblies with headsets and quick release axles
✓ Two suspended spindles assemblies with quick release axles (Road
AR
& Dumont)
✓ Adjustable handlebars
✓ A plastic boom shim
✓ Quick-release rear wheel skewer
✓ Brake cables and two lengths of brake cable housing
