OWNER’S MANUAL PAGE 24
The end of the cut cable must be sealed or it will fray and cause
a safety hazard. Crimp on one of the included cable ends.
Brake adjustment
Next, adjust the calipers. One of the nice things about the Avid disc brakes on your
Catrike is that they are very easy to adjust. If the caliper mounting bolts have been
tightened, loosen them.
• Adjust the brake pads; use the knurled plastic adjuster knobs on either side of the
caliper until the pads are firmly contacting the rotor. First screw the larger knob
(the one closest to the wheel hub) in until the disc is offset slightly away from the
wheel hub. Then screw the smaller knob in until the rotor is held tightly.
• Tighten the caliper mounting bolts.
• Back off the pad adjuster knobs until the disc spins freely and without
noise…about 1/2 turn each.
