OWNER’S MANUAL PAGE 14
Wheels
Prepare the wheels
Attach the brake rotors to the front wheels using the screws provided with the brakes.
Both the brake rotors and the tread on the tire are directional so attention must be paid to
how they are mounted. The direction of the brake rotor and tire must match!
Direction of rotation shown on brake rotors Direction of rotation shown on tire sidewall
Installing the derailleur hangar
Insert derailleur hanger into it recess located in the right dropout and tighten mounting
hardware.
