1 Introduction
Thank you for choosing Cavitar Welding Camera C400-H (later: Welding Camera)!
Welding Camera is a Finnish quality product developed and manufactured by Cavitar Ltd.
We hope you will be satisfied with your product.
Welding Camera is a highly compact and easy-to-use visualization system for the online
monitoring of various welding processes, including MIG, MAG and TIG processes.
Welding Camera contains several unique features to enable highest possible image quality.
These features include, among other things, spectral filtering combined with active laser
illumination.
The laser source of the system doesn’t require any control by the operator. Therefore, from
the operation point of view, the system doesn’t differ from a normal machine vision camera
system. Welding Camera is a class 3R laser product with a nominal ocular hazard distance
(NOHD) of 3 meters.
Please read this operating manual carefully before using Welding Camera.
Chapter 2 contains important safety information for the safe operation of Welding Camera.
Chapter 3 describes the properties of Welding Camera and Chapter 4 deals with the
installation of the system.
Chapter 5 describes the operation of Welding Camera.
Chapters 6 to 8 cover issues related to maintenance, service, support and warranty.
The actual appearance of software or components may vary.
The symbols below are applied throughout this operating manual:
