3 Properties
Welding Camera C400-H system typically consists of the following components:
CAMERA UNIT
• laser aperture label
• laser class 3R warning label
• easy-to-replace protective window
• adjustable working distance
• mounting threads
• integrated channels for air or liquid cooling
TEMPERATURE WARNING UNIT (TWU)
• generates audible and visible warning if camera temperature exceeds specified
boundaries
• power on/off button for the camera system
• sound off button for muting audible warning
• enables the use of an optional warning light system
POWER SUPPLY
• power supply DC 24 V, max 40 W, including 1,8 m long fixed cable
CABLES
• GigE cable (between camera unit and computer), standard length 10 m
• power cable (between camera unit and TWU), standard length 10 m
• power supply cable (between power supply and AC mains), standard length 2 m
ACCESSORIES
• 2x spare protective window
• 2x cooling hose connector with O-ring
• 2x hose clamp for cooling connector
• 1x hex key (1,5 mm) for working distance adjustment
INSTALLATION CD
• CAVITAR Capture-H software for controlling Welding Camera
• Operating manual
• Additional instructions:
O Guide for cooling
O Guide for external control via COM-port
O Guide for working distance adjustment
