Table 3.1. Welding Camera C400-H specifications.
Camera related
Default working distance
200 mm (good image quality within ± 15 mm)
Field of view (at default working distance)
approx. 40 mm x 30 mm
Max resolution
1440 pxl x 1080 pxl
Max frame rate (at full resolution)
Typically approx. 70 fps (computer dependent)
Max frame rate (with laser illumination)
100 fps
Optical
Wavelength
645 ± 10 nm
CW/Pulsed
Pulsed
Max average power
< 5 mW
Max pulse energy
< 22,9 J
Max pulse duration
< 2,7 s
Laser class (according to BS/EN 60825-1:2014)
3R
Nominal ocular hazard distance (NOHD)
3 m
Audial
TWU warning sound frequency
2900…3500 Hz
TWU warning sound pressure level
max 100 dB at 30 cm distance
Electrical
Power supply input voltage
AC 100-240 V, 47-63 Hz
Power supply output voltage
DC 24 V
Power supply power rating
Max 40 W
Mechanical
Camera unit dimensions (W x H x L)
38 mm x 48 mm x 99 mm (excl. connectors)
Camera unit weight
~ 360 g
Camera unit attachment
6x M3 and 4 x M4 mounting threads
TWU dimensions (W x H x L)
80 mm x 40 mm x 120 mm (excl. connectors)
TWU weight
~ 400 g
TWU attachment
4 x M3 and 2x M4 mounting threads
Environmental
Storage temperature
0…+50 °C
Operation temperature
+10…+40 °C
(1)
Indoor/outdoor use
Indoor use only
Humidity
max 80 % RH non-condensing
Altitude
max 2000 m above sea level
Pollution degree
PD2
Supply voltage fluctuations
±10 %
Overvoltage category
II
Pressure in integrated cooling circuitry
max 4 bar
Cooling liquid
mixture of pure water and inhibited glycol
(2)
Inner diameter of the cooling hose
6 mm
