Audio Connection
Connection method of Cayin MT-35 MK2 with other audio equipments Take pictures below for your reference.
To audio
output terminal
•
•
•
•
•
Pleace refer to the manuals of other connected equipments during the installation.
Do not insert the power cord into the main socket before all other equipments are
well connected.
Rrefers to right channel while L represents left channel.
Please take the right guidance for connection as wrong connection may cause
noise, low-grade function or damage.
Do not fasten signal cable together with power cable and speaker cables. It will
worsen the acoustic fidelity.
NOTE:
Wrong connection
Right connection
LINE1
LINE2
LINE3
INPUT
ZHUHAI SPARK ELECTRONIC EQUIPMENT CO., LTD.
260
RISK OF ELECTRIC SHOCK
CAUTION
DO NOT OPEN
SPEAKER OUTPUTRIGHT
48
LEFT SPEAKER OUTPUT
4 8
M MKT- 35 2
