4
Specifications
To reduce the risk of electric shock, do not remove the cover.
No user serviceable parts inside. Refer servicing to qualified
service personnel.
To reduce the risk of fire or electronic shock, do not expose
the unit to rain or moisture.
The lightning flash with arrowhead symbol is intended to alert user to the presence of uninsulated
“dangerous voltage” within the product's enclosure that may be of a risk shock to persons.
The exclamation point is intended to alert user to the presence of important operation and maintenance
(servicing) instructions accompanying the appliance.
RISK OF ELECTRIC SHOCK
CAUTION
DO NOT OPEN
ITEM
SPECIFICATIONS
Power Output
TR:18W+18W (RMS )
UL:35W+35W ( )
Triode mode
RMS Ultralinear mode
Frequency Response
8Hz55KHz (-3dB)
THD
1%(1kHz)
S/N Ratio
89dB
Input Sensitivity
300mV
Input Impedance
100kΩ
Output Impedance
4 , 8ΩΩ
Headphone Output Impedance
16Ω~300Ω
Input Connector
LINE1,LINE2,LINE3
× × W D H
326mm×272mm×184mm
Tube
12AX7×112AU7×2EL34×4
Net Weight
13.5kg
Power Consumption
260W
Working Condition
Temp0℃~40Humidity 20%80%
Storage Condition
Temp-20℃~70Humidity 20%90%
