WARNING: DO NOT CUT THE LOAD CELL CABLE!
3. Pull the load cell cable out of the conduits built into the frame channels. The chase
wire will be used to pull the new load cell cable through the formed channel.
4. Install the new load cell by reversing the preceding steps.
5. To verify correct load cell/junction box terminal matching, see the numbers on the terminals
inside the junction box and the corner numbering diagram in Figure 1: Load Cell
Configuration and Figure 2 Junction Box Connections.
6. Position load cells with load cell alignment arrow pointing up toward the deck. With the torque
wrench, tighten all mounting bolts to 75 ft./lbs.
7. Route the load cell cables in each corner so that the cable is free from possible contact with the
load cell or load foot. Pull cable towards junction box, (not to tight) and coil up extra length with
cable ties and securely store inside channel per figure 3 (Below).
8. Pass end of load cell cable through cable fittings in the NEMA 4X junction box.
Re-calibrate scale after a load cell replacement. Follow the calibration instructions in Chapter 8
- Weight Controller section of this manual.
