Troubleshoot a Bad Load Cell
Use the following values to trouble shoot a bad load cell.
Note: Red to Black is the input resistance. Very important
Note: Green to White is output resistance. Very Important.
LOAD CELL CONNECTION GUIDE
SHIELD CLEAR EXCITION + BLACK
EXCITION + RED SIGNAL - WHITE
SIGNAL + GREEN SENSE - BROWN
SENSE + BLUE
Load Cell Information/ Capacity
Resistance
Ink Ohms
2.5K
Red Black
.384
Red Green
.296
Red White
.296
Black Green
.294
Black White
.294
Green White
.351
