The CBE 520 Bulk Bag Filler is comprised of the following assemblies:
1. Digital Filler
Controller (104-1050)
The digital filler controller controls all aspects of the bag filling cycle. It is directly
responsible for controlling the solenoid valves and cylinder operated functions of
the machine.
2. Solenoid/ Pneumatic
Assembly (CBE-105----)
NOTE: App Specific
The solenoids or pneumatic valve control the air operated functions of the
machine. A configuration of three to six solenoid are located in the typical
solenoid control panel.
3. Start / Stop / E-Stop
Push Button Control
Station (115-900)
Allows for Manual Start, Stop, Pause and Emergency Shut Down of the Machine.
4. Dust Tight 12” Fill
Head w/ Slide-Gate Inlet
(CBE-502----)
NOTE App Specific
12” ID Bulk Bag Fill Head with Inflatable Bag Seal Cuff Designed to Inflate and
Seal Against the Inside of the Bulk Bag Neck to Prevent Displaced Air from
Escaping the Bag During the Bag Filling Process. A Slide-Gate Valve Starts and
Stops the Flow of Product into the Bag.
5. Bag Strap Release
Assembly (501-700)
Set of Four (4) Pneumatically Operated Latches that Hold the Bag Straps of the
Bulk Bag During the Filling Process. At the End of Each Bag Fill, the Strap
Releases will Automatically Release Freeing the Bag so that the Bag can be
Removed and the Filling Process Started Again.
6. Motor Control
Assembly (CBE 509----)
NOTE: App Specific)
Motor Controls to Operate Conveyor & Other Motorized Functions of the Machine
Including: Pre-Fill Bag Inflator, Vibratory Bag Settler, Discharge Conveyor and
Powered Accumulator Conveyors. (Controls Wired for Either 220 or 440 Volt / 3
Phase / 60 Cycle)
7. Live Roller Bag
Discharge Conveyor
(512-100)
A trigger switch that is integrated underneath the filling spout that automatically
initiates the bag fill upon the placement of empty bags onto the filling spout saving
the operator from manually pressing the start button to start the during fill. This
device is an excellent time saver.
8. Pop-Up Grid Deck
Vibratory Densifier (513-
300)
Vibratory Densifying Grid Table Designed to Lift a Pallet Off of a Live Roller
Conveyor, Settle or Densify Product in the Bag or Box without Vibrating the
Conveyor and Lowering the Pallet Back Onto the Live Roller Conveyor So It Can
Be Automatically Exited from the System After Densifying. Grid Deck Elevation is
Accomplished Via (4) Air Mounts. Controls Wired for Either 220 / 440 Volt / 3
Phase / 60 Cycle)
9. Rigid Mount Bag
Densifier Assembly
(Cushion Mounts w /Dual
Vibratory Motors(513-
1000
Vibratory Densifying Rigid Deck Mount Designed with dual motor vibrators
mounted on each side of the deck to Settle and/or Densify Product in Bulk Bag or
Box. Controls wired for either 220 / 440 Volt / 3 Phase / 60 Cycle)
9. 10’ Gravity Roller
Accumulation Conveyor
(515-100)
10’ Long X 54” Wide Gravity Roller Conveyor Designed to Receive Filled Bags
from the 512-100 Bag Discharge Conveyor so that a the Bag Filler can be Reset
for the Next Bag and Not be Tied Up Waiting on a Forklift.
