Bag Latch Open Timer
When this timer is activated the bag latches open for the time the timer is set for and close
again.
Input / Output Screen
The PLC screen displays which inputs and outputs are signaling on and off at any point
during the bag filling process. They are “on” when they are gray color or lite.
