FUNCTIONS
CARBATTERY ALARM(B1)
LEISUREBATTERY ALARM(B2)
When car battery voltage gets under 12V, Motor Battery Discharge alarm goes on and the symbol ref. 10
starts blinking.Alarm goes off when the voltage gets over 12.5V.
When leisure battery voltage gets 11.5V the Leisure Battery Reserve alarm goes automatically on, the
symbol ref. 08 starts blinking and you hear a short beep.
When the leisure battery voltage gets 10.5V, the Leisure Battery Discharge alarm goes automatically on,
the symbol ref. 8 starts blinking and you hear two short beeps. Alarms go off when the voltage gets over
12.5V.
MINIMUMVOLTAGECONTROL (BATTERY PROTECTION)
TANKS
a)
b)
DRINK WATER TANK REFILLING
DRINKWATERTANK ALARM
WASTE WATER TANKALARM
DIGITAL CLOCK
The electronic battery protection device cuts off the 12V users when leisure battery reaches 10V and
disables: pump, lights, awning light, and stove.
Symbolref.1isthevisualalarmsignal.
Itispossibletoreactivateallusersforoneminutebypressingtheon/offbutton(ref.5oncontrol
panel).
Thecontrolpanelautomaticallyturnsoffwithavoltagelowerthan9.5V.
Usersareautomaticallyreactivatedwhenvoltageisbiggerthan13.5V.
Thisdevicedoesn’tcontrolthefunctions:fridge,stepandtheauxiliaryexitDIR.
Drink water tank with electronic probe: levels are displayed numerically in % (steps of 10%) and
graphically by the level guage ref. 5
Waste water tank with screw probe.
Thisfunctionisusedduringthedrinkwaterrefillingandshowsthewaterlevelduringrefilling.
Toactivatethisfunctionpressthe“PROG”buttonref.1formorethan2seconds,untilthe“water
refilling”screenisdisplayed.
Thecontrolpanelbeepsinordertowarnthattankisgettingfilled:oneshortbeepat75-80%,twoshort
beepat85-90%andalongbeepat95-100%.
Toexitthisfunctionpressbuttonsref.2and3.
Alarmturnsonwhendrinkwaterlevelislowerthan10%ofthetankcapacityandautomaticallyturns
offwhenlevelexceeds20%.
Alarmisshownacoustically(whenengineisoff)andvisuallywiththesymbolref.7blinking.
Alarmturnsonwhenthewastewaterlevelexceedsthescrewsensorlevel.
Alarmisshownacoustically(whenengineisoff)andvisuallywiththesymbolref.9blinking.
Tosetclocksee“SETTING”.
