CBE PC150-EL - DS300-EL Distribution Box; Distribution Box Overview; Protection Fuses Explained

1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
11)
12)
5A fusetogivepowertotheawninglight.
10A fusetogivepowertothewaterpump.
10A fusetogivepowertotheheating/boiler.
20A fusetogivepowertothelightsgroup“A”.
20A fusetogivepowertothelightsgroup“B”.
30A fusetogivepowerto12V AESor3-wayfunctionfridge. The3-wayfunctionfridgeswitches
automaticallyoffwhentheengineisoff.
20A fusefortheauxiliarypowersupply(solarregulator),whichisdirectlyconnectedtotheleisure(B2)
battery.
25A fusefortheelectricalsteppowersupply,connecteddirectlytotheleisure(B2)battery.
3A fuseforthegaspowersupply(fridge,kitchen,boilervalve,etc.),Connecteddirectlytotheleisure
(B2)battery.
3A fuseforOUT D+simulatedexitprotection.
AESfridgeconnection;Itisabridge,whichexcludesthe3wayfunctionfridgeandisusedtoconnect
the AESfridgedirectlytotheB2.
etc.)
SimulatedoutputD+alternatortocontroltheelectricalstep, AESrefrigerator,electricaldrainingvalve,
coming-backoftheelectricalantenna.
DISTRIBUTIONBOX“DS300-EL”
PROTECTIONFUSES
