CBE pc220 - SYSTEM FUNCTIONS AND ALARMS; Battery Alarms and Protection

GB
ENGLISH
GB
17
FUNCTIONS
CARBATTERY ALARM(B1)
LEISUREBATTERY ALARM(B2)
Whencarbatteryvoltagegetsunder12V,MotorBatteryDischargealarmgoesonandthesymbolref.
10startsblinking. Alarmgoesoffwhenthevoltagegetsover12.5V.
Whenleisurebatteryvoltagegets11.5VtheLeisureBatteryReservealarmgoesautomaticallyon,the
symbolref.8startsblinkingandyouhearashortbeep.
Whentheleisurebatteryvoltagegets10.5V,theLeisureBatteryDischargealarmgoesautomatically
on,thesymbolref.8startsblinkingandyouheartwoshortbeeps. Alarmsgooffwhenthevoltagegets
over12.5V.
MINIMUMVOLTAGECONTROL (BATTERY PROTECTION)
TANKS
a)
b)
DRINKWATERTANKREFILLING
DRINKWATERTANK ALARM
WASTEWATERTANK ALARM
DIGITAL CLOCK
AWNINGLIGHT AUTOMATICTURNOFF
TEMPERATURE
Theelectronicbatteryprotectiondevicecutsoffthe12Vuserswhenleisurebatteryreaches10Vand
disables:pump,lights,awninglight,andstove.
Symbolref.1isthevisualalarmsignal.
Itispossibletoreactivateallusersforoneminutebypressingtheon/offbutton(ref.5oncontrol
panel).
Thecontrolpanelautomaticallyturnsoffwithavoltagelowerthan9.5V.
Usersareautomaticallyreactivatedwhenvoltageisbiggerthan13.5V.
Thisdevicedoesn’tcontrolthefunctions:fridge,stepandtheauxiliaryexit(directB2)
Drinkwatertankwithelectronicprobe:levelsaredisplayednumericallyin%(stepsof10%)and
graphicallybythelevelguageref.5
Wastewatertankwithscrewprobe.
Thisfunctionisusedduringthedrinkwaterrefillingandshowsthewaterlevelduringrefilling.
Toactivatethisfunctionpressthe“PROG”buttonref.1formorethan2seconds,untilthe“water
refilling”screenisdisplayed.
Thecontrolpanelbeepsinordertowarnthattankisgettingfilled:oneshortbeepat75%,twoshort
beepat85%andalongbeepat95%.
Toexitthisfunctionpressbuttonsref.2and3.
Alarmturnsonwhendrinkwaterlevelislowerthan10%ofthetankcapacityandautomaticallyturns
offwhenlevelexceeds20%.
Alarmisshownacoustically(whenengineisoff)andvisuallywiththesymbolref.7blinking.
Alarmturnsonwhenthewastewaterlevelexceedsthescrewsensorlevel.
Alarmisshownacoustically(whenengineisoff)andvisuallywiththesymbolref.9blinking.
Tosetclocksee“SETTING”.
Anelectronicdeviceswitchesofftheawninglightwhenengineisturnedon.
-Bothint.andext.temperatureshaveasensor,whichisplacedinsideoroutsideofthevehicle.
- Theprecisionofthetemperaturevalueis±1°C.
