CONNECTIONS
GB
ENGLISH
GB
21
WASTEWATERTANK
Toconnecttothewastewatertankprobewithscrews.
1
2
BLACK
13
DRINKWATERTANK
Toconnecttothedrinkwatertankprobe.
1
2
3 4
BLACK
14
1
9
8
16
CONTROL PANEL
Toconnecttothe16polesconnectorofthecontrolpanel.
BLACK
15
SIGNALS
1) +inputsignalcontactkeyenginestarting.
2) +inputsignal“S”netcomingfromtheCBEbatterycharger.
1
2
WHITE
16
FUSE
7
6
8
9
1) +exit AUX(solarregulator)(direct“B2”).
2-3) +exit3wayfunctionfridge
4) +exitelectricstep(direct“B2”).
5-6) +exitgasusers(fridge,küche,ecc...)(direct“B2”).
/ AES.
USERS
1
4
2
5
3
6
WHITE
17
FUSE
3
2
1
4
5
1) +exitheating/boiler,
2) +exitwaterpump,
3) +exitawninglight,
4-5-6) +exitlightsgroup“B”,
7-8-9) +exitlightsgroup“A”,
itdependsonthelightbutton.
itdependsonthepumpbutton.
itdependsontheawninglightbutton
itdependsonthelightbutton.
itdependsonthelightbutton.
USERS
1
4
7
2
5
8
3
6
9
WHITE
18
MASSE
Toconnecttothemains’masses.
WHITE
19
CARBATTERY
Toconnecttothepositivepoleofthecarbattery.
MASSE
Toconnecttothenegativepoleoftheservicesbatteryortothechassisofthe
vehicle.
SERVICESBATTERY
Toconnecttothepositivepoleoftheservicesbattery.
