CONTROL PANEL “PC380-BS”
DESCRIPTIONS
3) light button; this light switches
automatically off when you start up the engine
Awning awning
(it depend on the 12V button).
6) “PROG” button for system (see
SETTING).
setting
1) 12V button (lights and awning light).
5) On/off button (to turn on/off press for 2
seconds) at the start-up the display carries out
a functioning test and shows all symbols
(including unused symbols).
main
:
2) Button to switch the pump on and off.
4) Button with integrated twilight sensor to set the
intensity of the LED backlighting in a “night”
situation (see also the “TWILIGHT” function).
If the relevant LED is green the control panel is
on, if it is red an alarm is on (batteries, tanks,
etc.).
8) Button for control of car and leisure batteries
voltage (in Volt), load and recharge current (in
Ampere) for the leisure battery and for the
parameters’ setting (see SETTING).
NOTE: The watch is supplied from the leisure battery
(B2). Should B2 be disconnected, the watch
is able to keep working, without visualization,
for about week 2 .
7) Button for the control of fresh and waste water
tank (in %), for fresh water refilling function
operation (see “FRESH WATER TANK REFIL-
LING” function) and for the regolation of the
programmable parameters’ setting (see
SETTING).
