22
- LCD Display Functions -
Program Mode Display Windows
LIQUID LEVEL XX.XCM LID TEMP.-XXX C
CONTROL VALIDATION
TESTING: REMOTE CONTACTS
TEST PASS FAIL SKIP
#41A
o
This display will appear when
"PASS", "FAIL" or "SKIP" is select-
ed on display #40.
This menu tests remote alarm
contacts. Advances to next test
when "PASS", "FAIL" or "SKIP" is
selected.
Press this button to
toggle remote alarm
contacts.
Press this button if
test passes, to
advance to display
#41B and next test.
(next)
Press this button if
test fails, to advance
to display #41B and
next test.
(next)
Press this button to
skip test and
advance to display
#41B and next test.
(next)
LIQUID LEVEL XX.XCM LID TEMP.-XXX C
CONTROL VALIDATION
TESTING: LID TEMPERATURE
PASS FAIL SKIP
#41B
o
This display will appear when
"PASS", FAIL" or "SKIP" is selected
on display #41A.
This menu tests lid temperature
automatically and gives a "PASS"
or "FAIL" before advancing to the
next test.
Manually advances to next test
when "SKIP" is selected.
Press this button to
skip test and
advance to display
#41C and next test.
(next)
LIQUID LEVEL XX.XCM LID TEMP.-XXX C
CONTROL VALIDATION
VENT TEMPERATURE IS: -XXX C
PASS FAIL SKIP
#41C
o
o
l
This display will appear when
previous test passes or fails or
"SKIP" is selected on display #41B.
This menu tests vent temperature
automatically and gives a "PASS"
or "FAIL" before advancing to
the next test.
Manually advances to next test
when "SKIP" is selected.
Press this button to
skip test and
advance to display
#41D and next test.
(next)
LIQUID LEVEL XX.XCM LID TEMP.-XXX C
CONTROL VALIDATION
TESTING: PRINTER
TEST PASS FAIL SKIP
#41D
o
This display will appear when
previous test passes or fails or
"SKIP" is selected on display #41C.
This menu tests printer. Advances
to next test when "PASS", "FAIL"
or "SKIP" is selected.
Press this button to send
"TESTING PRINTER"
to the printer
Press this button if
test passes, to
advance to display
#41E and next test.
(next on page 23)
Press this button if
test fails, to advance
to display #41E and
next test.
(next on page 23)
Press this button to
skip test and
advance to display
#41E and next test.
(next on page 23)
