CCL 216B - Front Panel Indications; Connections; Precautions; Terminologies Used

- Direct sun light should not fall on the PBX.
- The PBX should be installed on the wall at a minimum of 2 ft height from the
floor. Note: The Comp any’s warrantee voids if the above points are not followed.
Front Panel Indications
Following is the descriptio ns of the LED indicato rs of the front panel of the PBX:
LED Name Description
POWER Blinking means PBX is working on Mains AC or Battery.
Connections
The PBX has the following connecto rs on its side panel:
Connectors Description
LINE 1 to LINE 2 Terminate the 1
st
and 2
nd
Junctio n Line here throug h a RJ Connecto r.
EXT 601 to EXT 616/ 624/ 632 Terminate the 1
st
to 32
th
Extensio n wires over here through a RJ
Connecto r.
AC 220V Connect the 2 pin main lead here.
witch on the Side of PBX It is for switching the PBX ON / OFF.
Note: The PBX is supplied RJ Connecto rs with short leads for termin ating the cables to RJ Sockets. It is reco mm ended to
Crimp RJ connecto rs directly to the cables in order to maintain the aesthetics.
Precautions :
- The Mains AC socket from where the PBX is given 220 V AC, should be separately made by taking direct
connectio ns from the MCB Box and no other Electrical appliance should be connected on this point.
. Terminologies Used .
JUNCTION LINE S - Telep ho ne Lines provided by the Departm ent of
Teleco m. EXTE NSIO N LINES - Extensio n Lines mean the EPABX extensio n lines.
. Programming the PBX .
To program most of the feature mentio n ed in this manual, program ming Passwo rd is to be entered from any extensio ns
(601, 602, 603, 604) throug h the following command :
#* 0000 (Here, 0000 is the default Passwo rd )
In case of any mistake while program ming, keep the Handset down and pick up again.
Wheneve r a correct input is entered , PBX will give one single acceptance tone and when wrong input is given, it will
give three tones.
. Allowed Table .
Numb e rs to be allowed to extensio ns whose L = 0, are to be defined in this table. For value of L refer “Juncti o n Dialing
Controls ”.
This table has 16 Locatio ns.
Proced ure: Dial #* 0000 + 43 QQ ABCD#
Where QQ= 01 to 16 (16 Locatio ns of the Table)
ABCD= The starting 4 digits of the Tel numb ers to be allowed to
extensio n. For less than 4 digits, dial # at the end of digits.
To clear this Table: Dial #* 0000 + 43 #
To clear a particular location of this table: Dial #* 0000 + 43 QQ #
. Auto Attendant Operations .
When the PBX is operated in this mode, the Junctio n caller gets a welcome
messag e. Three types of messag es can be record ed for the following 3 conditions:
Welco m e Messag e (10 Seconds)
Busy Messag e (5 Seconds)
No Answer Messag e (5 Seconds)
Auto Atten dant Enable/ Disable:
To set Junctio n in Auto Attend a nt mode:
Dial #*0000 + 10 J # where J= Junctio n Numb er 1 or 2
To set Junctio n in Direct Ring
mode: Dial #*0000 + 11 J
Message Recording/ Listening:
To Record Auto Attend a nt Messag e:
Dial #*0000 + 12 M #
Recording starts after a confirmatio n beep. There will be a second beep for recording end.
Listen Auto Attend a nt Messag e:
Dial #*0000 + 13M #
