CCL 216B - Emergency Call; Extension to Extension call; Flash Time setting; Flexible Numbering

1 Door Phone can be connected to the PBX.
Open the back cover of the Door Phone and connect 2 wires on the Terminal block.
These 2 wires are to be connected to any of the Extension port (from 601 to 632) of the PBX.
To define the Extension as the first Door Phone extension, program as below:
Dial #0000 + 80 NN #
Where, N = 01 - 32 (Representing the Extension numbers from 601 to 632)
To make the first Door Phone extension as a normal Extension, program as below:
Dial #0000 + 8000 #
Door Phone ring assignment
Dial #0000 + 82 NN # - To assign extensions to ring when Door Phone calls.
Where, N= 01 –32 (Representing the Extension numbers from 601 to 632)
Repeat the program for up to 3 Extensions maximum except door phone.
Dial #0000 + 82 # - To clear all programmed extensions for Door Phone calls.
. Emergency Call .
When any extensio n dials # 88, all extensio ns start ringing . All extensio ns get connected to the extensio n who had dialed
the Emerg ency code. All can talk in conference.
. Extension to Extension call .
Extensio n numb e rs in default are from 601 to 616 / 624 / 632 and can be chang ed to 2 digits / 3 digits or 4 digits numb e ri n g
as explained under the heading “Flexibl e Numb eri ng ”.
. Flash Time setting .
The Flash time of the PBX can be chang ed as describ ed below:
Dial #* 0000 + 00 L #
Here, L= 1 (for 0.8 secs) Default= 0.4 secs
2 (for 1.0 secs)
3 (for 1.2 secs)
4 (for 1.5 secs)
5 (for 1.8 secs)
. Flexible Numbering .
Extensio n numb ers can be chang ed to a desired numb er of 2 digit, 3 digit or 4 digits from 11 – 6999.
The numb e ring can either be 2digit, 3 digits or 4 digits in any combinatio n.
The flexible numb e r cannot begin with digits 0, 7, 8 and
9. Proced ure :
Dial #* 0000 + 9000 + # (This also resets all the flexible numb ering of the
PBX) Dial #* 0000 + 9 NN ABCD #
Where, N = Last two digits of the original extensio n numb e r (This original numb er always remains the one
that is printed on the MDF even if flexible numb ering is
done).
ABCD = The new Extensio n numb e r. For less than 4 digits, dial # at the end Of Extensio n Numb e r.
If all the new numb ers to be made in sequence then following program ming can be done with single program . This avoid s
lengthy program ming :
Dial #* 0000 + 9000 L K #
Where, L = Length of new numb e rs – 3 digits or 4 digits
K = First digit of the new numb ering . If K=2 then the numb ering will become 201 (or
2001) Onwards. Then all those Numb e rs can be chang ed throug h the following
program ming.
Default: 601,60 2, to 616 / 624 / 632
. Hot Line to Junction .
Some or all extensio ns can be program m ed to get Junctio n Line on lifting the Handset.
To dial internal numb e rs, dial * on lifting the Handset. You will get internal dial tone of the
PBX. To program an extensio n to get a free Junctio n line on lifting handset,
Dial #* 0000 + 20 NN#
Where, NN= last two digits of Extensio n numb ers that is to be program m ed for Direct Junctio n Access.
Dial #* 0000 + 20 # - To convert all Extensio ns in “Hot Line to Junctio n ” mode
Dial #* 0000 + 21 NN # - To convert NN Extensio n in normal mode.
Dial #* 0000 + 21 # - To convert all Extensio ns in normal mode.
Note: When all Extensio ns are converted to Hot Line then to get into the Programming mode, lift Handset
–Dial * # * 0000 + Whatever Program ming to be done.
Hot Line to Extension .
Some or all extensio ns can be program m ed to get connected to an Extensio n, on lifting the Handset.
To dial internal numb e rs, dial * on lifting the Handset. You will get internal dial tone of the
PBX. To program an extensio n in this mode,
