22 Hz ELECTROMAGNETIC TRANSMITTER USER GUIDE
Page 20 of 52
GETTING STARTED ͳ CD42ͳT2
Installing BaƩ eries
Load T2 Ba ery Carousel with
six (6) C-Cell alkaline ba eries.
Posi ve terminal (+) is always
opposite tension spring.
Replace carousel as shown.
Inspect cap and O-ring before
replacing.
Ensure O-ring is serviceable. A
bri le and/or deformed O-ring
may not properly seal. Lubricate
O-ring with a light coa ng of
petroleum jelly if dry.
Ensure O-ring groove and screws are clean and free of ruptures, dents,
or other damage.
NOTE: it is good prac ce to
always install new ba eries
prior to deployment.
