CDI CD42-T1A - CD42-T1 A, T1 AHP, T1 AVHP SWX Kit

22 Hz ELECTROMAGNETIC TRANSMITTER USER GUIDE
Page 26 of 52
GETTING STARTED ͳ CD42ͳT1A/T1AHP/T1AVHP
CD42-T1A, T1AHP, T1AVHP Op onal Pressure Switch (SWX) Kit
The T1A, T1AHP, and T1AVHP SWX Kits are similar in design and
func on. Retrofi  ng is a simple ma er of removing exis ng ba ery cap
and carousel, and replacing with a confi gured SWX.
Confi guring T1A, T1AHP, T1AVHP SWX
The T1A, T1AHP, and T1AVHP SWX are factory-set for pressure
ac va on. There is a single dip switch for Latching (transmi er stays on
once ac va on pressure is reached) or Non-Latching (transmi er ON
state follows pipeline pressure; i.e., will turn on or off depending on
pressure).
CD42-T1A SWX (stainless steel)
CD42-T1AVHP SWX ( tanium)
CD42-T1AHP SWX
(stainless steel)
CD
42
-T
1A
S
WX
(
st
a
CD
42
-T
1A
HP
S
WX
Non-Latching Latching
