22 Hz ELECTROMAGNETIC TRANSMITTER USER GUIDE
Page 25 of 52
GETTING STARTED ͳ CD42ͳT1A/T1AHP/T1AVHP
Installing BaƩ eries
Load Ba ery Carousel with six (6) AA-Cell
alkaline ba eries. Posi ve terminal (+)
is always opposite tension spring.
Replace carousel as shown.
Inspect cap and O-ring before replacing.
Ensure O-ring is serviceable. A bri le and/or deformed O-ring may not
properly seal. Lubricate O-ring with a light coa ng of petroleum jelly
if dry.
Ensure threads are clean and free of ruptures, dents, and other damage.
Replace cap. Your CD42-T1A is now ac ve.
Placing Into Service
See pg. 34
NOTE: it is good prac ce to
always install new ba eries
prior to deployment.
NOTE: T-Series Transmi ers have no “ON-OFF” switch. Unless
your transmi er is factory-confi gured for Delay On opera on,
it will begin opera on when cap is installed.
