SPECIFICATIONS
SPECIFICATIONS
Transmi ers
CD42-T0
Pipeline Dia: 6 – 12 in.
[152 – 305 mm]
Pressure, max : 2,500 psi [172 bar]
Dimensions: 7.56 in. x 1.625 in.
[192.1 x 41.3 mm]
Ba eries: N-Cell (6) Alkaline
Ba ery Life: Standard pulse: 168 hrs
Material: 304 Stainless Steel
Range, open air: 39  [11.8 m]
Opera ng
Temp Range:
– 40°F to 140°F
[– 40°C to 60°C]
CD42-T1
Pipeline Dia: 8 – 28 in.
[203 – 711.2 mm]
Pressure, max : 2,500 psi [172 bar]
Dimensions: 10.375 in. x 3.0 in.
[263.53 x 76.2 mm]
Ba eries: AA-Cell (6) Alkaline
Ba ery Life: Standard pulse: 500 hrs
Skip-one pulse: 678 hrs
Material: Nylon
Range, open air: 45  [13.7 m]
65  [19.8 m]
Opera ng
Temp Range:
– 40°F to 140°F
[– 40°C to 60°C]
Programmable run  mes of up to 12 months on
six (6) alkaline ba eries)
